Hypnotize
Designed to be a real Supernaked machine. Whether navigating the urban jungle or parked on a street corner, this lightweight, powerful Supernaked is sure to turn heads. Z400 – Hypnotize.
Available Colours
- Candy Lime Green / Metallic Spark Black
- Pearl Robotic White / Metallic Matte Graphenesteel Gray
Prices from*
Brochure
* Due to Brexit and the ongoing increases in shipping costs, click here to see our most up to date price lists.
Technical Specifications
Engine
- Engine Type Liquid-cooled, 4-stroke Parallel Twin
- Compression Ratio 11.5:1
- Valve System DOHC, 8 valves
- Bore x Stroke 70 x 51.8 mm
- Displacement 399 cm³
- Intake System N/A
- Fuel System Fuel injection: Ø 32 mm x 2
- Ignition System N/A
- Starting System Electric
- Lubrication Forced lubrication, wet sump
Performance & Transmission
- Maximum torque 38 N•m {3.9 kgf•m} / 8,000 rpm
- Maximum power 33.4 kW {45 PS} / 10,000 rpm
- CO2 emission 100 g/km
- Transmission 6-speed, return
- Clutch Wet multi-disc, manual
- Primary Reduction Ratio 2.219 (71/32)
- Gear Ratios 1st 2.929 (41/14)
- Gear Ratios 2nd 2.056 (37/18)
- Gear Ratios 3rd 1.619 (34/21)
- Gear Ratios 4th 1.333 (32/24)
- Gear Ratios 5th 1.154 (30/26)
- Gear Ratios 6th 1.037 (28/27)
- Final drive Sealed chain
- Final reduction ratio 2.929 (41/14)
Brakes & Suspension
- Brakes, Front Single semi-floating 310 mm petal discs. Caliper: Single balanced actuation dual piston
- Brakes, Rear Single 220 mm petal disc. Caliper: Dual-piston
- Suspension, Front 41 mm telescopic fork
- Suspension, Rear Bottom-Link Uni-Trak, gas-charged shock with adjustable preload
Frame & Dimensions
- Frame type Trellis, high-tensile steel
- Trail 92 mm
- Wheel travel, front 120 mm
- Wheel travel, rear 130 mm
- Tyre, front 110/70R17 M/C 54H
- Tyre, rear 150/60R17 M/C 66H
- L x W x H 1,990 x 800 x 1,055 mm
- Wheelbase 1,370 mm
- Ground clearance 145 mm
- Fuel capacity 14 litres
- Seat height 785 mm
- Curb mass 167 kg
